Quick Answer: A hi-low adjustable bed raises and lowers its sleeping deck, typically from 10 to 27 inches, so the mattress surface matches wheelchair seat height for safe lateral transfers. The ideal transfer height is mattress level with the chair seat. Most manual wheelchair seats sit between 18 and 20 inches; power wheelchair seats range higher. A low-profile mattress (under 10 inches) maximises the usable height range.
In This Guide
Reading Time: 7 minutes
Hi-Low Beds vs Standard Adjustable Bases
Most people who walk into a mattress store asking about adjustable beds are thinking about head and foot angle, things like reading position, snoring relief, or zero-gravity for back pain. A hi-low adjustable bed does something fundamentally different: it raises and lowers the entire sleeping surface, deck and all, so that someone using a wheelchair can get level with the mattress.
A standard lifestyle adjustable base sits at a fixed height, usually somewhere between 7 and 14 inches off the floor. The head and foot sections tilt, but the overall deck height stays put. That is great for couples who want different positions. It does nothing for someone who needs to slide laterally from a wheelchair onto a sleeping surface at the same height.
A hi-low bed, by contrast, can go very low (often as low as 10 to 11 inches to the top of the mattress) for independent or assisted transfers, and very high (up to 27 inches or more on some homecare models) when a caregiver needs access for bathing, dressing, or medical care. Some hi-low models also include head and foot adjustment, so you get both functions in one frame.
Hi-Low vs Lifestyle Adjustable Base: Key Differences
- Height range: Hi-low moves the entire deck up and down (typically 10"-27"). Lifestyle adjustable bases have fixed overall height with tilting sections only.
- Transfer purpose: Hi-low designed for wheelchair and mobility aid transfers. Lifestyle bases designed for position comfort.
- Speed: Hi-low beds use heavier-duty actuators that move faster for caregiver efficiency. Lifestyle bases are quieter and slower.
- Weight capacity: Hi-low homecare frames typically handle 400-700 lbs. Lifestyle bases vary widely.
- Side rails: Hi-low beds can be fitted with half or full rails. Lifestyle bases rarely include rails.
- Mattress compatibility: Both require compatible mattresses, but hi-low bed frames typically pair best with low-profile, firm mattresses.
Why Transfer Height Is the Critical Number
The single most important variable in any wheelchair-to-bed transfer is matching surface heights. When the bed is at the same height as the wheelchair seat, the person transferring, whether doing so independently or with assistance, moves horizontally rather than fighting gravity. Even a two or three inch height difference turns a manageable slide into a lift, which dramatically increases caregiver injury risk and makes independent transfers much harder or impossible.
Wheelchair Seat Heights: What the Data Shows
Transfer surface height research from the U.S. Access Board's Medical Diagnostic Equipment Advisory Committee (2013) found that seat heights for people using mobility devices ranged from just above 17 inches to nearly 29 inches depending on device type. Manual wheelchair seats typically measure 18 to 20 inches from the floor. Power wheelchair seats, particularly those with seat elevation features, can measure up to 28 or 29 inches. Scooters generally sit at 22 to 26 inches. This range means there is no single "universal" transfer height. The hi-low bed's adjustability is what closes this gap: you set the deck height to match your specific chair, not a published average.
Caregiver safety is a secondary but equally real concern. Transfer-related musculoskeletal injuries are among the most common occupational injuries for home support workers and family caregivers in Canada. When the bed can be raised to a comfortable working height, caregivers do not need to bend deeply at the waist to assist. When it is lowered to chair height for the transfer, the lateral movement is controlled and efficient. Both adjustments reduce loading on the caregiver's lumbar spine.
Calculating Your Ideal Height
Measure the height from the floor to the top of the wheelchair seat cushion. That is your target transfer height for the top of the mattress. If your wheelchair seat is 19 inches and you plan to use a mattress that is 8 inches thick, the bed deck needs to reach approximately 11 inches to deliver a 19-inch total mattress surface height. Knowing this number before you shop will save you a lot of confusion about height specifications.
Choosing the Right Mattress for a Hi-Low Bed
The mattress is not an afterthought in a hi-low bed setup. The wrong mattress can defeat the purpose of the adjustable frame entirely.
Keep the Profile Low
A 12 or 14 inch luxury mattress might be wonderful on a standard bed frame, but it eats into your hi-low adjustment range from the top down. If your hi-low bed's deck goes from 10 to 27 inches and you put a 14 inch mattress on it, your actual transfer surface height ranges from 24 to 41 inches. That is too high at the low end for most wheelchair transfers. A mattress of 8 to 10 inches keeps your options open.
Firm Enough for Safe Transfers
A very soft mattress compresses significantly when you sit on the edge to transfer. That softness is comfortable for sleeping but destabilising during a lateral transfer. You want a firmer surface, at least medium-firm, so the edge holds its shape when body weight moves across it. Brad, who has helped a number of Brantford families set up homecare sleeping arrangements over the years, recommends looking at our Restonic ComfortCare line for hi-low applications: the 1,222 individually wrapped coils in the Queen model provide consistent support without the sinkage that can make transfers unpredictable.
Pressure Management
People who spend extended time in bed, whether recovering from surgery or managing a progressive condition, are at higher risk for pressure injuries. A mattress for hi-low bed use should have some pressure relief at the shoulders and hips even while staying firm enough for transfers. Pocket coil construction with a modest comfort layer achieves both. Very thick memory foam alone is not ideal because it is both too soft for transfers and because slow-response materials can allow moisture and heat to accumulate under prolonged contact.
The Mattress Edge Test
When you are testing a mattress for hi-low bed use, sit on the edge and shift your weight. A good mattress for this application should compress no more than about an inch under that load and should feel stable rather than like you are tipping. If the edge sinks significantly when you sit on it, the mattress will complicate every transfer. Our showroom lets you test this properly before committing. Call (519) 770-0001 and ask Brad to have the firmer options ready for your visit.
How a Lateral Transfer Works With a Hi-Low Bed
Step 1: Position and Lock the Wheelchair
Bring the wheelchair alongside the bed at a slight angle (typically 30 to 45 degrees). Lock both wheelchair brakes. Remove the footrests and, if applicable, the armrest nearest the bed. This creates the clearest path for the transfer.
Step 2: Lower the Bed to Wheelchair Seat Height
Use the hi-low control to lower the bed deck until the top of the mattress matches the wheelchair seat height. Do this before the person to be transferred sits on the edge, as adjusting height mid-transfer adds instability.
Step 3: Place and Secure the Transfer Board
Slide a transfer board (sometimes called a sliding board) under one thigh and across to the mattress surface, bridging the gap. A smooth, slightly curved board with a non-slip underside works best. The board should span the gap completely without rocking.
Step 4: Execute the Lateral Slide
Weight-shifting toward the mattress, the person slides along the board in small movements, moving hips across first. Caregivers assist by guiding at the hips, not by pulling the arms or shoulders. A gait belt can help the caregiver maintain control without awkward holds.
Step 5: Remove the Board and Adjust Height for Sleeping
Once the person is fully on the mattress, remove the transfer board. Raise the bed to a comfortable sleeping height, add pillows for positioning, and release the wheelchair brake. If side rails are in use, raise the appropriate rail.
8 min read
OT Assessment and Ontario Funding Options
In Ontario, a hi-low homecare bed is considered a medical device rather than a consumer product, which means there are funding pathways that do not apply to lifestyle adjustable bases.
The Assistive Devices Program (ADP) through Ontario's Ministry of Health covers a portion of certain assistive devices for eligible Ontarians. Whether a hi-low bed qualifies depends on individual assessment and diagnosis. An occupational therapist (OT) home assessment is the key to accessing this pathway. The OT documents the specific safety need, the current transfer setup, and the risk of injury or decline without the recommended equipment. That documentation is what moves the application from "comfort preference" to "medically indicated."
If you are connected to a local Community Care Access Centre (now known as Home and Community Care Support Services in Ontario), your care coordinator can arrange an OT home visit. You can also request an OT referral through your family physician or specialist. The Brantford Community Health Centre and Brant Community Healthcare System are both starting points for people in our area.
Homecare Bed Setup in Brantford and Brant County
When Brantford families are setting up homecare sleeping arrangements, they often come to us after the OT has already made a recommendation but before they have chosen a specific mattress. The OT specifies the functional requirements (transfer height, edge firmness, pressure management) and we help match those requirements to the actual products available. We have worked with families from Brantford, Paris, Burford, and St. George on homecare setups, and our white glove delivery team is experienced with bedroom configurations where space is tight and the setup needs to be precise. If your OT has given you a written recommendation, bring it with you and we will work from that document.
Shop: Adjustable Bed Frames at Mattress Miracle
Shop This Topic at Mattress Miracle
Adjustable base options at Mattress Miracle:
- Deluxe Adjustable Bed (15 Massage Modes)
- Affordable Adjustable Bed (German Motor)
- Restonic SleepBeat SE1005 Base
Or adjustable bed frames in our Brantford showroom.
Find Your Perfect Mattress at Mattress Miracle
We are a family-owned mattress store in Brantford, helping our community sleep better since 1997. Come try mattresses in person and get honest, no-pressure advice.
441 1/2 West Street, Brantford, Ontario
Call 519-770-0001Frequently Asked Questions
What is the height range of a hi-low adjustable homecare bed?
Most homecare hi-low beds adjust from approximately 10 to 27 inches from the floor to the top of the mattress deck. Some models go lower (as low as 7 inches) for people who transfer from the floor, and some go higher for caregiver access. The usable transfer height is the deck height plus the mattress thickness, so a 10-inch deck with an 8-inch mattress gives you an 18-inch transfer surface at the lowest position.
What mattress thickness works best with a hi-low bed?
Most occupational therapists recommend keeping the mattress at 8 to 10 inches for hi-low bed applications. A thicker mattress eats into the low-end height range, potentially making the lowest position too high for a comfortable wheelchair-level transfer. A thinner mattress also tends to be firmer, which is an advantage for transfer stability at the edge.
Can Ontario's ADP fund a hi-low adjustable bed?
The Assistive Devices Program (ADP) covers certain assistive devices for eligible Ontarians, and hi-low homecare beds may qualify depending on the individual's diagnosis, functional needs, and OT documentation. An occupational therapist assessment is typically required to support the funding application. Contact Home and Community Care Support Services in your region or ask your family doctor for an OT referral to start the process.
Do I need a special mattress for a hi-low homecare bed, or will any mattress work?
You need a mattress that is compatible with an adjustable base if the hi-low bed also has head and foot articulation. More importantly, you need a mattress that is low-profile (8 to 10 inches), firm enough for stable transfers, and appropriate for the amount of time the person will spend in bed. A standard mattress designed for a fixed box spring is often too thick and sometimes too flexible for a hi-low frame.
Does Mattress Miracle in Brantford carry mattresses suitable for homecare beds?
Yes. We carry a range of mattresses, including firmer, lower-profile options well-suited to homecare applications. Brad at (519) 770-0001 can discuss your specific hi-low bed model and OT recommendations to help you find the right fit. Our white glove delivery team can also assist with setup and placement in your home.
Sources
- U.S. Access Board, Medical Diagnostic Equipment Technical Advisory Committee. (2013). Recommendations on Standards for Accessible Medical Diagnostic Equipment. U.S. Architectural and Transportation Barriers Compliance Board. access-board.gov
- Defloor, T. (2000). The effect of position and mattress on interface pressure. Applied Nursing Research, 13(1), 2-11. doi.org/10.1016/s0897-1897(00)80013-x
- Jacobson, B.H., Boolani, A., & Smith, D.B. (2008). Changes in back pain, sleep quality, and perceived stress after introduction of new bedding systems. Journal of Chiropractic Medicine, 8(1), 1-8. doi.org/10.1016/j.jcme.2008.09.002
- Waters, T.R., & Rockefeller, K. (2010). Safe patient handling for rehabilitation professionals. Rehabilitation Nursing, 35(5), 216-222. doi.org/10.1002/j.2048-7940.2010.tb00050.x
- Okamoto-Mizuno, K., & Mizuno, K. (2012). Effects of thermal environment on sleep and circadian rhythm. Journal of Physiological Anthropology, 31(1), 14. doi.org/10.1186/1880-6805-31-14
