Coil gauge refers to the wire thickness used to make the springs in a mattress. The gauge scale works inversely: lower numbers mean thicker wire, which makes coils firmer and more durable. A 12-gauge coil is thicker and firmer than a 15-gauge coil. Most quality pocket coil mattresses use 14 to 16-gauge wire for a balance of support and responsiveness. Heavier sleepers generally benefit from lower (thicker) gauge coils.
Coil gauge rarely makes it onto a mattress showroom tag. Most brands advertise coil count prominently while leaving wire thickness unmentioned, even though gauge has a significant effect on how a mattress actually feels and how long it lasts.
Understanding coil gauge gives you one more concrete measurement to compare when evaluating innerspring or hybrid mattresses. It is not the only variable that matters, but it is a meaningful one that too few Canadian mattress shoppers know to ask about.
How the Coil Gauge Scale Works
The gauge system for wire is counterintuitive for most people. Gauge numbers run inversely to wire diameter: a lower gauge number means a thicker, heavier wire, and a higher gauge number means a thinner, lighter wire.
This convention comes from the wire drawing industry, where gauge historically indicated how many times a wire had been drawn through a die to reduce its diameter. More draws produced a thinner wire with a higher gauge number.
In mattress coil springs:
- 12 gauge: Very thick wire, very firm coil
- 13-14 gauge: Thick wire, firm to medium-firm
- 15-16 gauge: Standard wire, medium feel
- 17+ gauge: Thin wire, softer and more responsive
The practical range for quality mattress coils is typically 13 to 17 gauge. Coils outside this range are either too rigid for comfortable sleep (below 12) or too thin to maintain adequate support over time (above 18).
How Gauge Affects Mattress Feel
Thicker (lower gauge) wire requires more force to compress. This means the coils resist body weight more firmly, which translates into a firmer feel at the sleep surface. Thicker coils also recover from compression more rapidly, which provides a more responsive, "on top of the mattress" feel.
Thinner (higher gauge) wire compresses more easily under the same load. Mattresses with higher-gauge coils feel softer and more conforming. They allow more body contouring, which can reduce pressure-point discomfort for side sleepers but may provide less lumbar support for back sleepers.
Importantly, coil gauge interacts with coil count. A mattress with a high coil count (many coils) can use thinner gauge wire while still providing firm overall support, because the load is distributed across more coils. A mattress with fewer coils may need lower gauge (thicker) wire to maintain adequate support. This is why coil count and gauge are more meaningful together than either is alone.
A randomised controlled trial published in The Lancet (Kovacs et al., 2003) comparing firm and medium-firm mattresses in 313 adults with chronic low back pain found that medium-firm surfaces significantly outperformed firm surfaces for pain reduction and functional improvement. Medium-firm coil systems, achieved through appropriate gauge selection, provide the balance of support and compliance most associated with reduced musculoskeletal loading during sleep.
8 min read
Coil Gauge Chart for Canadian Buyers
| Gauge Range | Wire Thickness | Feel | Best For |
|---|---|---|---|
| 12 gauge | Very thick | Very firm | Institutional, heavy-duty use |
| 13-13.5 gauge | Thick | Firm | Heavier sleepers (200+ lbs), stomach sleepers |
| 14-14.5 gauge | Medium-thick | Medium-firm | Back sleepers, average weight sleepers |
| 15-16 gauge | Medium | Medium | Side sleepers, lighter sleepers, combination sleepers |
| 17+ gauge | Thin | Soft/responsive | Comfort and luxury layers, micro-coil toppers |
These ranges apply to single-zone mattresses. Zoned mattresses use different gauges in different areas, typically thinner wire at the shoulder zone and thicker wire at the hip and lumbar zone.
Coil Gauge vs. Coil Count: Different Things
Coil count and coil gauge are the two main quantitative specifications for innerspring and hybrid mattress support systems, and they measure completely different things.
Coil count is how many individual springs are in the mattress. Higher counts generally mean better body contouring (more springs responding to localised pressure) and better motion isolation (especially in pocket coil systems). A quality Queen mattress typically has 800 to 1,200 pocket coils.
Coil gauge is how thick each spring's wire is. Thicker wire means firmer, more durable coils. Neither metric alone is sufficient to evaluate a mattress. A high coil count with very thin wire may feel soft and responsive initially but may not provide adequate long-term support. A low coil count with very thick wire may feel firm and rigid without the contouring that comes from more coils.
The combination of a moderate to high coil count (800-1,200 in a Queen) with an appropriate gauge (14-16 depending on body weight) is the specification profile most associated with quality hybrid and innerspring mattresses.
"Most customers come in asking about coil count, which is a good question. But coil gauge matters just as much. A mattress with 800 coils in 14-gauge wire can support a heavier person more durably than 1,200 coils in 17-gauge wire, even though the second mattress has more coils. When I am evaluating a mattress, I look at both numbers together, not just one."
How Gauge Affects Longevity
Thicker wire has greater fatigue resistance. Steel under repeated compression cycles undergoes a process of metal fatigue, where microscopic cracks form in the wire and accumulate over time. Thicker wire contains more steel mass, which means it takes longer for fatigue to reach a critical level that causes a spring to lose its recovery force.
A mattress with 14-gauge coils will generally maintain its support properties for longer than an identical mattress using 16-gauge coils, assuming the same steel quality and coil design. For sleepers who plan to keep a mattress for 8 to 10 years or more, coil gauge is a legitimate durability consideration alongside foam density.
Heavier sleepers should pay particular attention to coil gauge because higher body weight compresses springs more deeply on each sleep cycle, which accelerates the fatigue process. A 200-pound sleeper on 16-gauge coils will reach the fatigue threshold faster than a 140-pound sleeper on the same coils.
Recommended Gauge by Body Weight
These are general guidelines. Personal sleep position, comfort preference, and the specific coil count and design of the mattress all affect the final recommendation:
- Under 130 lbs: 15-17 gauge comfortable and durable. Higher gauge provides better pressure relief for lighter sleepers.
- 130-180 lbs: 14-16 gauge. Standard range that suits most average-weight sleepers across positions.
- 180-230 lbs: 13.5-15 gauge. Slightly thicker wire provides better support and longer durability at this weight range.
- Over 230 lbs: 12-14 gauge. Thicker wire recommended to maintain adequate support without accelerated coil fatigue.
Restonic Coil Specs at Mattress Miracle
Mattress Miracle has carried Restonic mattresses in Brantford since 1997. Restonic uses individually wrapped pocket coil systems in their Canadian product line, with documented coil specifications that our team can share with you.
The Restonic ComfortCare Queen uses 1,222 individually wrapped pocket coils. The Revive line, which targets heavier sleepers and those with specific back conditions, uses coil configurations designed for durability and progressive support. If you would like to know the specific gauge of any Restonic model in our showroom, ask us directly. We can look up the specification from manufacturer documentation.
We stock mattresses across a range of coil gauges to accommodate different body weights and sleep preferences. The best way to find the right coil gauge for your needs is to come in, tell our team your weight and sleep position, and try the models we recommend. Feel in person will always tell you more than a number on paper.
Coil gauge in mattresses refers to the wire thickness, with lower gauge numbers indicating thicker, firmer wire and higher numbers indicating thinner, softer wire. Mattress Miracle at 441½ West Street in Brantford carries mattresses with various coil gauges and can explain how gauge affects firmness and durability. Brad notes that coil gauge combined with coil count determines the overall support profile of a mattress. Call (519) 770-0001 for a technical explanation of mattress construction.
Shop: Compare Our Mattresses
Shop This Topic at Mattress Miracle
Popular picks at Mattress Miracle:
- Restonic ComfortCare Dalton & Albany pocket-coil mattress
- Whitney bamboo mattress
- Somnia posture pillow
Or compare our mattresses in our Brantford showroom.
Find Your Perfect Mattress at Mattress Miracle
We are a family-owned mattress store in Brantford, helping our community sleep better since 1997. Come try mattresses in person and get honest, no-pressure advice.
441 1/2 West Street, Brantford, Ontario
Call 519-770-0001Frequently Asked Questions
Is a higher coil gauge always lower quality?
No. Higher gauge (thinner wire) is appropriate for lighter sleepers, for mattress comfort layers, and for micro-coil luxury layers. Quality is determined by appropriate gauge for the application. A 16-gauge coil is not lower quality than a 13-gauge coil for a 130-pound side sleeper. It may be the better choice for that application.
Does coil gauge affect noise?
Coil noise is primarily related to coil type (Bonnell and offset coils can squeak if springs rub each other) and steel quality, not gauge specifically. Pocket coil mattresses, where each spring is individually wrapped in fabric, are virtually silent regardless of gauge because the springs cannot contact each other directly.
Can I find out the coil gauge of my current mattress?
Try contacting the manufacturer directly with your mattress model number from the law label. Manufacturers often provide detailed spec sheets upon request. Alternatively, contact the retailer where you purchased the mattress. Retailers who know their products should have access to this information.
Is coil gauge the same for all coils in the mattress?
In a uniform support system, yes. In a zoned mattress, different gauges are used in different body zones: thinner wire in the shoulder zone for more give, thicker wire in the lumbar and hip zones for more support. Asking specifically about the gauge in the lumbar zone is useful for back pain sufferers.
Sources
- Kovacs, F.M., Abraira, V., Pena, A., et al. (2003). Effect of firmness of mattress on chronic non-specific low-back pain: randomised, double-blind, controlled, multicentre trial. The Lancet, 362(9396), 1599-1604. doi:10.1016/S0140-6736(03)14792-7
- National Mattress. (2024). What Is a Mattress Coil Gauge? nationalmattress.ca
- Saatva. (2024). Coils in Mattress: Guide to Coil Types, Coil Count, and Coil Gauge. saatva.com
- Puffy. (2024). Mattress Coil Gauge Chart: Your Official Firmness Guide. puffy.com
